Màn hình cảm ứng Mitsubishi GT167M HMI 10.4 Inch
- Màn hình cảm ứng HMI Mitsubishi GOT1000: GT1675M-STBA
- Kích thước & Độ phân giải màn hình: 10.4″ SVGA [800 × 600 dots]
- Loại mành hình hiển thị: TFT color LCD (high brightness, wide viewing angle)
- Màu sắc: 65,536 colors
- Nguồn cấp: 100-240VAC
- Dung lượng bộ nhớ: 15MB
Thông số kỹ thuât:
| Item | Specification | ||||
| GT1675M-STBA GT1675M-STBD | GT1675M-VTBA GT1675M-VTBD | GT1675-VNBA GT1675-VNBD | GT1672-VNBA GT1672-VNBD | ||
| Display*1 | Type | TFT color LCD (high-brightness, wide viewing angle) | TFT color LCD | ||
| Screen size | 10.4″ | ||||
| Resolution | SVGA: 800 600 [dots] | VGA: 640 480 [dots] | |||
| Display size | 211(W) 158(H)[mm] | ||||
| No. of displayed characters | 16-dot standard font: 50 chars. 37 lines (2-byte) 12-dot standard font: 66 chars. 50 lines (2-byte) | 16-dot standard font: 40 chars. 30 lines (2-byte) 12-dot standard font: 53 chars. 40 lines (2-byte) | |||
| Display colors | 65536 colors | 4096 colors | 16 colors | ||
| View angle*2 | Up/down/right/left: 88 | Right/left: 45 , Up: 30 , Down: 20 | |||
| Intensity | 400 [cd/m2] | 450[cd/m2] | 200[cd/m2] | ||
| Intensity adjustment | 8-step adjustment | 4-step adjustment | |||
| Life | Approx. 43,000 hours (operating ambient temperature: 25 C) | Approx. 52,000 hours (operating ambient temperature: 25 C) | |||
| Cold-cathode fluorescent tube (replaceable), with backlight OFF detection function. Backlight off time and screen save time can be set. | |||||
| Backlight | Life*3 | Approx. 50,000 hours or more | |||
| (Time for display intensity reaches 50% at operating ambient temperature of 25 C) | |||||
| Touch panel *10 | Type | Analog resistive type | |||
| Key size | Min. 2 2 [dots](per key) | ||||
| No. of simultaneous touch points | Simultaneous touch prohibited*4 (1 point only) | ||||
| Life | 1,000,000 times or more (operating force 0.98N or less) | ||||
| Human sensor | Detection distance | – | |||
| Detection range | – | ||||
| Detection delay time | – | ||||
| Detection temperature | – | ||||
| Memory*5 | C drive | 15MB built-in flash memory (for saving project data and OS) | 11MB built-in flash memory (for saving project data and OS) | ||
| Life (No. of writings) | 100,000 times | ||||
| GT15-BAT type lithium battery | |||||
| Battery | Backed up data | Clock data, maintenance time notification data, system log data and SRAM user area (500KB) | |||
| Life | Approx. 5 years (operating ambient temperature: 25 C) | ||||
| Built-in interface | RS-232*7 | RS-232, 1ch Transmission speed: 115200/57600/38400/19200/9600/4800bps, Connector shape: D-sub 9-pin (male) Application: Communication with connected devices, connection to personal computer (project data upload/download, OS installation, FA transparent function) | |||
| RS-422/485 | RS-422/485, 1ch Transmission speed: 115200/57600/38400/19200/9600/4800bps Connector shape: 14-pin (female) Application: Communication with connected devices | ||||
| Ethernet | Data transfer system: 100BASE-TX, 10BASE-T, 1ch*8 Connector shape: RJ-45 (modular jack) Application: Communication with connected devices, gateway function, connection to personal computer (project data upload/download, OS installation, MES interface function) | ||||
| USB | USB (full-speed 12Mbps), host 1ch Connector shape: TYPE-A Application: Data transfer and storage | ||||
| USB (full-speed 12Mbps), device 1ch Connecter shape: TYPE Mini-B Application: Connection to personal computer (project data upload/download, OS installation, FA transparent function) | |||||
| CF card | Compact flash slot, 1ch, Connector shape: TYPE Application: Data transfer, data storage, GOT startup | ||||
| Optional function board | 1ch for optional function board installation | ||||
| Extension unit | 2ch for communication unit/optional unit installation | ||||
| Buzzer output | Single tone (tone length adjustable) | ||||
| Protective construction | JEM1030 Front: IP67f*6 In panel: IP2X | ||||
| External dimensions (without USB port cover) | 303(W) 214(H) 49(D)[mm] | ||||
| Panel cut dimensions | 289(W) 200(H)[mm] | ||||
| Weight (excl. mounting brackets) | 2.1[kg] | 2.3[kg] | |||
| Applicable software packages | Screen design software | GT Works3 Version1 | |||
| Simulation software | |||||
| Model name | Screen size [resolution] | Display | Display colors (number of colors) | Power supply | Memory size | Remarks | ||||
| GT16 | GT1695 | GT1695M-XTBA | 15″ XGA [1024 × 768 dots] | TFT color LCD (high brightness, wide viewing angle) | 65,536 colors | 100-240VAC | 15MB | Compatible with multimedia & Video/RGB | ||
| GT1695M-XTBD | 24VDC | |||||||||
| GT1685 | GT1685M-STBA | 12.1″ SVGA [800 × 600 dots] | TFT color LCD (high brightness, wide viewing angle) | 65,536 colors | 100-240VAC | 15MB | Compatible with multimedia & Video/RGB | |||
| GT1685M-STBD | 24VDC | |||||||||
| GT167M | GT1675M-STBA | 10.4″ SVGA [800 × 600 dots] | TFT color LCD (high brightness, wide viewing angle) | 65,536 colors | 100-240VAC | 15MB | Compatible with multimedia & Video/RGB | |||
| GT1675M-STBD | 24VDC | |||||||||
| GT1675M-VTBA | 10.4″ VGA [640 × 480 dots] | TFT color LCD (high brightness, wide viewing angle) | 65,536 colors | 100-240VAC | 15MB | Compatible with multimedia & Video/RGB | ||||
| GT1675M-VTBD | 24VDC | |||||||||
| GT1675-VNBA | TFT color LCD | 4,096 colors | 100-240VAC | 11MB | – | |||||
| GT1675-VNBD | 24VDC | |||||||||
| GT1672-VNBA | TFT color LCD | 16 colors | 100-240VAC | 11MB | – | |||||
| GT1672-VNBD | 24VDC | |||||||||
| GT166M | GT1665M-STBA | 8.4″ SVGA [800 × 600 dots] | TFT color LCD (high brightness, wide viewing angle) | 65,536 colors | 100-240VAC | 15MB | Compatible with multimedia & Video/RGB | |||
| GT1665M-STBD | 24VDC | |||||||||
| GT1665M-VTBA | 8.4″ VGA [640 × 480 dots] | TFT color LCD (high brightness, wide viewing angle) | 65,536 colors | 100-240VAC | 15MB | Compatible with multimedia & Video/RGB | ||||
| GT1665M-VTBD | 24VDC | |||||||||
| GT1662-VNBA | TFT color LCD | 16 colors | 100-240VAC | 11MB | – | |||||
| GT1662-VNBD | 24VDC | |||||||||
| GT1655 | GT1655-VTBD | 5.7″ VGA [640 × 480 dots] | TFT color LCD (high brightness, wide viewing angle) | 65,536 colors | 24VDC | 15MB | – | |||
| Handy GOT | GT1665HS-VTBD | 6.5″ VGA [640 × 480 dots] | TFT color LCD (high brightness, wide viewing angle) | 65,536 colors | 24VDC | 15MB | – | |||
